ASUS Dual Radeon RX 560 4GB AMD Graphic Card

Product Description

Features of ASUS Dual Radeon RX 560 4GB AMD Graphic Card

Wing-blade fan design incorporates drooped tips on each blade to reduce drag.0dB technology lets you enjoy light gaming in relative silence.Dual ball fan bearings can last up to twice as long as sleeve bearing designs.DirectCU II copper heatpipes make direct contact with the die for better cooling.Auto-Extreme Technology uses automation to enhance reliability.
The Sweet Spot Performance
ASUS Dual Radeon RX 560 4GB AMD Graphic Card comes equipped with Patented Wing-Blade Fans for max air flow with 105% more air pressure. The fans are IP5X dust-resistant for improved reliability and a longer lifespan. While exclusive Auto-Extreme Technology with Super Alloy Power II components facilitates superior stability, GPU Tweak II provides intuitive performance tweaking, thermal controls, and system monitoring.
Wing-blade Fan Design
They’re pretty flyOur patented Wing-blade fan design adds drooped tips to each fan blade in order to reduce drag.
0dB Technology
Quiet intelligenceTo eliminate unnecessary noise, a stop mode halts all fans when the GPU temp falls below 50 degrees and power consumption is low.
Dual Ball Fan Bearings
2x longer lifespanDifferent bearing types have unique pros and cons. Ball bearings excel at durability and can last up to twice as long as sleeve bearing designs.
DirectCU II
First contactCopper heatpipes make direct contact with the die for improved thermal transfer.
Auto-Extreme Technology
Precision automated manufacturingAuto-Extreme Technology is an automated manufacturing process that sets new standards in the industry by allowing all soldering to be completed in a single pass. This reduces thermal strain on components and avoids the use of harsh cleaning chemicals, resulting in less environmental impact, lower manufacturing power consumption, and a more reliable product overall
Stainless Steel Bracket
Steel yourselfThe mounting bracket of the Dual has been beefed up with 304 Stainless Steel that’s harder and more resistant to corrosion.
GPU Tweak II
Monitor, tweak, and tuneThe ASUS GPU Tweak II utility takes graphics card tuning to the next level. It allows you to tweak critical parameters including GPU core clocks, memory frequency, and voltage settings, with the option to monitor everything in real-time through a customizable on-screen display. Advanced fan control is also included along with many more features to help you get the most out of your graphics card.
AMD Radeon™ Software
Change the way you gameThe latest Radeon™ Software unleashes the full potential of your GPU with day-0 drivers optimized for new game releases and a highly customizable gaming experience.
144-hour Validation Program
“Extensive” may be an understatementA 144-hour validation program puts cards through a series of stringent tests to ensure compatibility with the latest games.

AMD Radeon™ RX 560
4.0 GB GDDR5 (128bit), Connection via 3.0
Active Cooling (Dual-Slot)
1x HDMI, 2x DisplayPort
Power Supply: 1x 8pin, 450 W PSU recommended
Card length approx. 242 mm

Specifications of ASUS Dual Radeon RX 560 4GB AMD Graphic Card

Brand
ASUS
Model
DUAL-RX560-4G
Form Factor
Radeonâ„¢ RX 560
Interface
Interface
Yes x 1 (Native HDMI 2.0b) Yes x 2 (Native DisplayPort 1.4) HDCP Support Yes (2.2)
Chipset
GPU
AMD Radeon RX 560
Core clock
1199 MHz
Stream Processors
1024
Memory
Memory Clock
6.8 Gbps
Memory Size
4GB
Memory Interface
128-bit
Memory Type
GDDR5
3D API
OpenGL
OpenGL 4.5
Ports
HDMI
Yes x 1 (Native HDMI 2.0b)
DisplayPort
Yes x 2 (Native DisplayPort 1.4)
General
Max Resolution
Digital Max Resolution 5120 x 2880
HDCP Ready
HDCP Support Yes (2.2)
Power Connector
1 x 8-pin
